Provision Page Overview

The Provision page is the main page of Lantronix Provisioning Manager. This page provides a dashboard view of all discovered devices and their attributes. From here you can provision, configure, and update one or more devices concurrently.

To view the Provision page, click Provision on the sidebar menu.

Lantronix Provisioning Manager: Provision Page

Lantronix Provisioning Manager: Search

Use the search bar at the top of the Provision page to quickly find devices.

Your search criteria can use one or more device attributes; partial search is supported:

  • Name
  • Firmware version
  • Serial number
  • IP address
  • MAC address
  • Operation status

Discover Devices

The Provision page displays discovered devices of the type(s) selected in the device type selection setting.

To refresh the list of discovered devices, click the Discover (refresh) icon discover below the search bar.

  • LPM discovers devices on the same subnet as the computer running LPM or in the IP range(s) configured in Network Settings.
  • LPM discovers devices by network interface. If a device has two network interfaces connected, it will be listed twice.
  • If LPM does not display a known device, you may want to change the Timeouts and Retries configuration and ensure the appropriate IP range is configured in Network Settings.

Logging in to Discovered Devices

LPM attempts to log in to discovered devices via the credentials you provide; see Important Information on Device Credentials for more information.

If LPM is unable to log into a device, the Operation Status wlll display "Error: Failed to Login to device". If this message appears, confirm the provided credentials are correct.

Provision Devices

Lantronix Provisioning Manager: Provision

Click the checkboxes to select one or more devices, then click one of the provisioning function buttons (Assign IP, Export Configuration, etc.) below the search bar.

See the documentation for more information about these functions.

Note

Available provisioning functions will depend on the device(s) selected. If a function is grayed out it is not supported for your selection.

Device Attributes

Lantronix Provisioning Manager: Attributes

LPM displays the following attributes for each discovered device:

Attribute Description
Name Name of the device.
Firmware Version Firmware installed on the device. For devices with two firmware banks, the firmware in the active bank is shown in bold text.
Serial Number Serial number of the device.
IP IP address of the device.
MAC MAC address of the device.
Operation Status Status of the operation currently being performed. An error message appears if the operation was not successful; double-click the message for more information.
Progress Progress bar showing the progression of the operation currently being performed.
Device Menu Click the three-dot menu   menu   to view a menu of supplemental actions that can be performed on that device. The list of actions will depend on your device.
View Log - Displays the log for the specified device.
Enter Credentials - Set the device's specific credentials; these will not be saved when LPM is closed.
Connect - Attempts to connect to the device if the connection is lost.
Get Device Info - Displays the device name, serial number, extended firmware version, device description, and device ID.
